Molecular distillation is an evolved form of the traditional distillation process with higher energy efficiency, reduced risk of head degradation, and unmatched separation purity. Hence, it is widely used in prominent industries, including pharmaceuticals, food, petrochemicals, cosmetics, and biotech.

Primarily used for liquid-liquid distillation mixture separation, the molecularization equipment delivers optimal results for heat-sensitive compounds and for mixtures of compounds with close boiling points.

Through this blog, we aim to provide you with all the key details about molecular distillation, its working principle, applications, and critical operational tips.

Molecular distillation relies on the molecules' mean free path to ensure high-purity separation at a significantly lower temperature range. In simplified terms, the travel distances of heavier and lighter gas molecules differ, and by placing a condenser plate at the right distance, a high-purity separation is achieved.

Also, molecular distillation is performed under high-vacuum and low-pressure conditions, which lowers the compounds' boiling points. Thereby directly reducing the energy requirement for the distillation process.

Molecular Distillation Process Phases

• The raw material is filtered and degassed to remove particulates and dissolved gases.
• Importance: Prevents contamination and ensures stable, uninterrupted operation.

• The feed is gently heated before entering the evaporator.
• Importance : Lowers viscosity, improving flow and enabling uniform film formation.

​​​​

• A wiped film system spreads the feed into a thin layer over the heated surface.
• Importance : Increases surface area, enhances heat transfer and evaporation efficiency.

► Evaporation (High Vacuum)

• Under deep vacuum, volatile components evaporate at reduced temperatures.
• Importance : Protects heat-sensitive compounds from thermal degradation.

► Molecular Transport (Short Path)

• Vapor molecules travel only a very short distance to the condenser, experiencing minimal collisions.
• Importance : Ensures precise separation based on molecular properties.

► Condensation

• Vapors are condensed on a cooled internal condenser surface.
• Importance : Enables efficient recovery of purified distillate.

► Product Collection

• Distillate and residue are collected separately for further use or refinement.
• Importance : Ensures proper segregation and downstream processing of products.

​​​​

Experiencing production bottlenecks in the distillation process?Talk to our engineersfor high-performance and effective solutions!

Considered to be a more efficient and safer method for specialized liquid-liquid separation, industrial molecular distillation has a wide range of applications. Moreover, this process is primarily used where uncompromised product quality is the primary requirement.

• Pharmaceutical Industry
  Purification of heat-sensitive APIs, vitamins, and bioactive compounds.

• Food & Nutraceuticals
  Concentration and refinement of omega-3 fatty acids, edible oils, and flavor compounds.

• Essential Oils & Fragrances
  Gentle separation of volatile compounds without altering aroma profiles.

• Petrochemical Industry
  Refining of heavy hydrocarbons, lubricating oils, and waxes.

• Chemical Processing
  Purification of high-boiling and specialty chemicals with close boiling points.

• Cannabis & Herbal Extraction
  Isolation of cannabinoids (like CBD/THC) with high purity.

• Polymer & Resin Industry
  Removal of monomers, oligomers, and impurities from polymers and resins.

• Cosmetics Industry
  Refinement of active ingredients and oils used in skincare formulations.

Speak to our engineersfor industry-specific distillation solutions or request a free equipment demo!

Traditional distillation, while being an effective and widely accepted separation technique, fails to match the quality and purity requirements in specialized cases. These cases include:

• Dealing with heat-sensitive compounds.
• Separating compounds with a higher boiling point.
• High purity separation, usually for pharmaceutical and biotech production.
• Faster completion time and lower energy consumption requirements.

Thus, a molecular or short path distillation system is preferred in such cases to achieve the desired results and manufacture products that meet the client's demands and requirements. Other advantages of using molecular distillation over traditional methods include:

1. Low Temperature Operations – Lower Energy Requirements

Molecular distillation is a type ofshort path distillationthat uses high-vacuum conditions to lower the compounds' boiling points. Thus, it reduces the overall energy consumption as the distillation process is conducted at significantly lower temperatures.

2. Prevents Thermal Degradation – Prevent Batch Rejection

The molecular distillation system projects a thin film of the compound, increasing the surface area to facilitate the process, reduce the residence time, and protect heat-sensitive compounds.

3. Ideal Handling of High Boiling Point Compounds

Compounds such as heavy oils, vitamins, plant extracts, and lubricating oils are difficult, or almost impossible, to separate by traditional distillation. That is precisely why molecular distillation is used for such cases.

4. Lab and Industrial Applications – For Scalable Production

Used in small-scale lab research and commercial production, molecular distillation is a flexible process that can be easily scaled to meet production needs.

Molecular distillation equipment from Achieve Chem ensures risk-free upscaling and enables you to replicate lab results at pilot or commercial scales.

Achieve Chem further improves the energy efficiency of molecular distillation by leveraging our R&D capabilities and precision engineering. We design and manufacture lab, pilot, and commercial equipment to meet industry- and product-specific requirements. Moreover, our ISO-certified manufacturing facilities ensure that each product complies with international quality and safety standards.

Request a price quote or get

professional assistance on choosing the right distillation equipment!

Two manufacturers using the same raw materials for the same product can have distinct production requirements and challenges. Standard equipment fails to provide adequate results for versatile production and changing demands. Achieve Chem addresses these challenges with customized molecular distillation equipment tailored to your particular production.

Speak with our engineers or visit our facilities to tailor the equipment to your specific production requirements!

Q.1: What are the key considerations to ensure a longer operational life of the molecular distillation system?

A: Use the following tips:

• Maintain stable vacuum conditions and ensure leak-free operation to protect system efficiency and internal components
• Control and calibrate temperature precisely to avoid thermal stress and degradation of equipment parts
• Perform regular cleaning and preventive maintenance to prevent fouling, scaling, and mechanical wear
• Use properly pre-treated feed material to minimize contamination and extend component life.

Q.2: What are the different components in a molecular distillation system?

A: A molecular distillation system has the following components:

• Evaporator & Wiper System : Forms a thin heated film for rapid evaporation and efficient separation
• Feed & Discharge System : Ensures uniform input and continuous removal of distillate and residue
• Vacuum System : Maintains low pressure to enable low-temperature distillation
• Condenser & Cooling System : Quickly condenses vapors to recover purified components.

Q.3: What is the importance of temperature control in distillation?

A: Accurate temperature control in the distillation process protects heat-sensitive compounds from degradation and ensures higher process efficiency. Precise temperature control is also crucial for shorter residence time and high-purity yield.

Q.4: What services are offered by Achieve Chem?

A: Achieve Chem is a one-stop solution for your lab, pilot, and industrial scale production requirements. We cover a wide range of services, including pre-purchase consultation, professional installation, and post-delivery maintenance.

Q.5: How soon can I expect the product delivery?

A: The standard delivery time is 60 days. However, it can vary depending on the equipment scale and additional customizations.
