Plant Growth Chamber
Description
Technical Parameters
Multi-application Growth Chambers – Precision and Versatility
Every batch tested or cultivated inside Achieve Chem Plant Growth chambers delivers precise results. And this precision extends to lab (80 - 180 L) and industrial-scale (up to 2000L) bio-cultivation applications. On top of that, our smart growth chambers can accommodate a wide range of compounds and create ideal compound-specific conditions . This results in superior efficiency , optimal growth , and accurate lab results.
Healthy and Quality-Compliant Plant Growth
Our Plant Growth Chambers are built on top of our flagship Intelligent Artificial Climate Chamber technology. Designed specifically for facilitating plant growth, these chambers have larger dimensions, a more powerful lighting system for photosynthesis, a wider range of temperature control, and an additional CO2 fuelling system.
Key Specifications
Laboratory-scale Plant Growth Chamber
|
Model |
Capacity |
Internal (External) Dimensions L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Illumination |
|
PRX-80A |
80 L |
540×540×350 (590×590×1200) |
0–50°C ±0.5°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-80B |
80 L |
540×540×350 (590×590×1200) |
0–50°C ±0.5°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-180A |
180 L |
540×540×650 (590×590×1340) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-180B |
180 L |
540×540×650 (590×590×1340) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-180C |
180 L |
540×540×650 (590×590×1340) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-180D |
180 L |
540×540×650 (590×590×1340) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-280A |
280 L |
540×540×960 (590×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-280B |
280 L |
540×540×960 (590×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-280C |
280 L |
540×540×960 (590×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-280D |
280 L |
540×540×960 (590×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
Pilot-scale Plant Growth Chamber
|
Model |
Capacity |
Internal (External) Dimensions L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Illumination |
|
PRX-380A |
350 L |
540×540×1210 (590×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-380B |
350 L |
540×540×1210 (590×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-380C |
350 L |
540×540×1210 (590×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-380D |
350 L |
540×540×1210 (590×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-500A |
450 L |
620×620×1150 (680×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-500B |
450 L |
620×620×1150 (680×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-500C |
450 L |
620×620×1150 (680×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-500D |
450 L |
620×620×1150 (680×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-600A |
600 L |
1240×540×960 (1300×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-600B |
600 L |
1240×540×960 (1300×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-600C |
600 L |
1240×540×960 (1300×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-600D |
600 L |
1240×540×960 (1300×590×1640) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-800A |
800 L |
1240×540×1210 (1300×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-800B |
800 L |
1240×540×1210 (1300×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-800C |
800 L |
1240×540×1210 (1300×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-800D |
800 L |
1240×540×1210 (1300×590×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
Industrial-scale Plant Growth Chamber
|
Model |
Capacity |
Internal (External) Dimensions L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Illumination |
|
PRX-1000A |
1,000 L |
1240×620×1210 (1300×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-1000B |
1,000 L |
1240×620×1210 (1300×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-1000C |
1,000 L |
1240×620×1210 (1300×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-1000D |
1,000 L |
1240×620×1210 (1300×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-1200A |
1,200 L |
1800×620×1210 (1860×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-1200B |
1,200 L |
1800×620×1210 (1860×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-1200C |
1,200 L |
1800×620×1210 (1860×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-1200D |
1,200 L |
1800×620×1210 (1860×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-1500A |
1,500 L |
1860×620×1210 (1900×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-1500B |
1,500 L |
1860×620×1210 (1900×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-1500C |
1,500 L |
1860×620×1210 (1900×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-1500D |
1,500 L |
1860×620×1210 (1900×680×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
PRX-2000A |
2,000 L |
2345×705×1145 (2485×765×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
3,000 lx |
|
PRX-2000B |
2,000 L |
2345×705×1145 (2485×765×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
12,000 lx |
|
PRX-2000C |
2,000 L |
2345×705×1145 (2485×765×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
22,000 lx |
|
PRX-2000D |
2,000 L |
2345×705×1145 (2485×765×1890) |
0–50°C ±1.0°C |
50–95% RH ±5% |
30,000 lx |
|
|
 |
 |
 |
Remarks
- 600 - 1000 L models come with a double-door configuration
- 1200 L and above come with a triple-door configuration
- Each Plant Growth Chamber is further subcategorized into Type A , Type B , Type C , and Type D based on the illumination intensity.
Note:For specialized applications that require prolonged cultivation at temperatures below 10°C or above 40°C, and relative humidity below 50% RH, we highly recommend you speak with our engineers.
Lab/Industrial Scale Plant Growth Chamber – Product Highlights
One Equipment, Multiple Applications
Key applications of our chambers include cultivating plant growth, tissue culture, seedling cultivation, rare insect breeding, BOD determination, and specialized cultivation of highly sensitive bio-compounds and organisms.
Accurate Environmental Simulations
Through automation and precise engineering, Achieve Chem plant growth chamber China allows you to recreate ideal temperature and humidity levels for rapid growth in a shorter duration and at a significantly lower resource cost.
30-stage Operations
You can divide the cultivation process into 30 different stages and customize the time duration for each stage. This will help you adjust the artificial climate inside the chambers to match the specific variations, including day and night conditions.
Durable and Safety-compliant Interior
We use industry-compliant stainless steel for the inner chambers of our artificial plant growth equipment. This keeps plants and highly sensitive bio-compounds safe from contamination, ensuring the highest quality cultivation.
Customizable Alarm System
This is an optional feature that allows you to set a safety limit on the plant growth chamber temperature level to protect the plants from excessive heat. The operations halt immediately once the threshold temperature limit is crossed.
Sync Process Monitoring with Data Analysis
With the smart and advanced RS485 interface, our equipment allows you to connect experiment monitoring with data recording, which further translates to streamlined data analysis without introducing data discrepancy.
Modular Design
Our modular Plant Growth Chamber reduces overall downtime by cutting short the maintenance and cleaning time. Part replacement, regular maintenance, and scheduled cleaning do not require dismantling the whole equipment, ultimately saving time and cost.
Optimized Resource Utilization
As per Liebig's Law of the Minimum, the scarcest resource dictates the cultivation process. Thus, Achieve Chem equipment allows you to optimize each cultivation resource in the most efficient way, ensuring better yield at lower cost.
Customize Your Plant Growth Chamber
Precision and Versatility – Two Key Reasons Behind the Need for Customization
Different plant species grow differently and require diverse environmental conditions for optimal growth. Standard plant growth chambers are designed for standard usage, which means they cannot adjust to plant-specific cultivation conditions, resulting in subpar cultivation quality and growth speed. Your standard laboratory plant growth chamber fails to provide this precision as it cannot control CO2, temperature, and humidity within the required range and maintain consistency for longer durations.
Customizable Smart Plant Growth Chamber
Achieve Chem introduces customization wherever necessary to ensure that the plant growth chamber specifications align with your cultivation requirements. From dimensions of the growth chamber to temperature range and alarm systems, the flexibility of customization extends to every major parameter, including:
- Temperature range
Set minimum and maximum temperatures according to plant safety level or experimental requirements.
- Relative humidity
Adjustable humidity levels for controlling plant transpiration and growth conditions.
- Light intensity
Customizable illumination levels to meet different photosynthetic requirements.
- Photoperiod
Programmable light/dark cycles to simulate day and night conditions.
- CO₂ concentration
Adjustable CO₂ levels for controlled photosynthesis and plant-growth studies.
- Chamber dimensions
Customized internal volume and usable growing area based on sample quantity.
- Shelving configuration
Adjustable number, height, and arrangement of shelves for different plant sizes.
- Control system
Programmable control of temperature, humidity, lighting, CO₂, and other operating parameters.
- Alarm settings
Customizable high/low limits for temperature, humidity, CO₂, and other critical parameters.
- Data logging
Configurable monitoring and recording intervals for experimental data.
- Door configuration
Single-, double-, or multi-door configurations depending on accessibility and chamber size.
- Safety features
Customizable interlocks, alarms, over-temperature protection, and other safety controls.
Why Partner with Achieve Chem
Partnering with a credible, trusted equipment manufacturer, such as Achieve Chem, solves half of your plant cultivation problem by introducing smart equipment and necessary automation. With 2 certified manufacturing facilities spanning 279,000 m² and 6 branches, Achieve Chem is a global manufacturer that provides lab and industrial-scale solutions across prominent industries. With 18 years of manufacturing experience, our company delivers equipment built to international quality standards, supporting accurate laboratory testing, safe production upscaling, and energy-efficient industrial operations.
Achieve Chem Service Highlights
- Lab-scale, pilot-scale, and industrial-scale chamber manufacturing capabilities.
- Customized chamber dimensions, shelving, lighting, and control configurations.
- Comprehensive testing and quality inspection before dispatch.
- Installation, commissioning, operator training, and technical support.
- After-sales maintenance, troubleshooting, and spare-parts assistance.
Applications of a Plant Growth Chamber
Crop Stress Testing
Provides a controlled environment to test how plants respond to harsh environments and how it affects their overall growth.
Plant Breeding
Used for the process of modifying plant species with controlled cross-pollination to combine desirable traits and to weed out diseases.
Genetic Engineering
A more precise version of breeding, where plant species are modified with DNA technology for precise lab applications.
Crop Physiology
Allows scientists and researchers to determine how crop plants function, factors impacting their growth, and how they respond to environmental changes.
Talk to Our Experts for Smart Investment Advice
Expert guidance and advice from Achieve Chem before investing in a lab-scale or industrial Plant Growth Chamber have proven to be a game changer for our clients. The way our experts design plant cultivation chambers based on your specific needs and operational scale saves a considerable amount of time, effort, and money for you. On top of that, their comprehensive guidance covers every critical aspect, including customization, process optimization, and post-delivery services.
Schedule a consultation with our experts and get key operational insights to choose the right equipment and the adequate extent of equipment customization.
Achieve Chem Certifications
 |
 |
 |
 |
FAQs
What is a plant growth chamber and how does it work?
What are plant growth chambers used for?
What environmental conditions can be controlled in a plant growth chamber?
What is the difference between a plant growth chamber and a greenhouse?
What temperature and humidity can a plant growth chamber maintain?
How do I choose the right plant growth chamber?
Can a plant growth chamber be customized?
